Viewing Data

About Viewing Data

View functions provide basic image manipulation options. Changes are applied to the current data set and its reconstructions.



A human figure appears in the lower left corner of each view to indicate the orientation of the image.

Other relevant orientation indicators appear in each view, including: H (head), F (foot), L (left), R (right), A (anterior) and P (posterior).

2D Orientation

This symbol is shown when displaying 2D images.
Art-No. 60919-56EN

Date of issue: 2019-10-07
